Model

PH-10C

ORP-20C

Range

0.00   to 14.00PH

-1000mV   to +1000mV

Resolution

0.01

1mV

Accuracy

0.01   PH±1 digit

1mV±1   digit

Display

3-1/2   Digit LCD （Blue   back light）

Impedance

＞10¹²Ω

Temperature   Compensation

ATC   probe or Manual Fixed Resistance【PT-100】

Current   Output

4-20Ma   Max.load 800_Ω

Control   Action

Relay   NO/OFF

Current   on Contact

220VAC   Max.3A/110VAC Max.1.5A

Control   Limit

Hi/Lo

Set   Point

2

Power

110V,220V   AC±12%,50/60Hz

Cut   Out Dimension

92×92×125(H×W×D)   【mm】

Weights

1.2kg
